Chapter 10 – Emergency Operation
50 TB60/66J – 0084030EE
Use the following procedure to manually lower the main
boom.
. Slowly turn the knob (refer to Figure 0.5) to open
the bleed down valve. Control the rate of descent
by turning the knob.
Figure 10.5 – Emergency Lowering Knob
A Warning
The potential for an accident increases when safety
devices do not function properly. Death or serious
injury can result from such accidents. Fully close
the emergency lowering knob before operating the
aerial platform.
2. Turn the knob to close the cylinder bleed down
valve.
Figure 10.4 – Platform Foot Switch
5. Hold the engine/emergency power switch in the
emergency power position.
6. Hold the appropriate function toggle switch in the
desired direction.
Emergency Lowering
The main boom can be lowered in an emergency us-
ing the emergency lowering knob at the base of the lift
cylinder. The emergency lowering knob allows the main
boom to be lowered only. Only use this method if the
engine will not start and the emergency power system
will not work.
A Danger
Pinch points exist between boom components and
between the booms and turntable. Death or serious
injury will result if the booms or platform lowers onto
personnel. Make sure all personnel stand clear while
lowering the booms.
Emergency
Lowering Knob
Platform Foot
Switch
Figure 10.3 – Upper Controls
Top Front
Start Switch
Emergency Stop Engine/Emergency
Power Switch
Drive/Boom
Selector
