Chapter 2 – Specifications
8 TB60/66J – 0084030EE
General Specifications – TB66J
Aerial Platform
Working height 2.9 m (72′)
Maximum platform height 20. m (66′)
Horizontal reach 7. m (56′)
Main boom
Articulation -° to +72°
Extension 0 to 8.33 m (0 to 328″)
Turntable rotation 360° continuous
Turning radius, inside 4.7m (5′ 5″)
Wheelbase 3 m (0′)
Ground clearance 33 cm (3″)
Maximum wheel load 5,900 kg (3,000 lbs)
Maximum ground pressure .3 kPa (78 psi)
Weight, GVW
Approximate ,96 kg (26,220 lbs)
Stowed width 2.4 m (7′ .5″)
Stowed length 0 m (33′)
Stowed height 2.7 m (8′ 9″)
Platform
Dimensions
Standard steel 76 cm x 52 cm (30″ x 60″)
Rated work load 227 kg (500 lb)
Optional aluminum 76 cm x 244 cm (30″ x 96″)
Rated work load 227 kg (500 lb)
Rotation 90° CW to 80° CCW
Maximum number of occupants 2 people
Optional AC generator 220 VAC
Function Speed
Turntable rotation, 360 degrees 65 to 75 seconds
Main boom
Up 64 to 75 seconds
Down 64 to 75 seconds
Extend 65 to 75 seconds
Retract 35 to 45 seconds
Jib
Up 7 to 3 seconds
Down 7 to 3 seconds
Platform rotation, 70 degrees 6 to 20 seconds
Drive
High, booms stowed 4.8 km/h (3.0 mph)
Low, booms elevated 0.96 km/h (0.6 mph)
Drive System
Standard Four wheel drive
Optional Two wheel drive
Gradeability – theoretical 4x4 65%
Tires
Foam Filled, 2 ply 38 cm x 50 cm (5″ x 9.5″)
Electrical System
Voltage 2 V DC negative chassis ground
Source Two - 2 V 550 CCA batteries
Fluid recommended distilled water
Hydraulic System
Maximum pressure 7,250 kPa (2,500 psi)
Reservoir capacity 99 l (26. US gal)
System capacity 32 l (35 US gal)
Maximum operating temperature 93°C (200°F)
Hydraulic fluid recommended
Above -2°C (0°F) Mobil DTE-3M (ISO VG32)
Below -2°C (0°F) Mobil DTE-M (ISO VG5)
Engine
Diesel Cummins B3.3
Diesel Deutz F4L-20F
Fuel Tank Capacity
Diesel 5 l (40 US gal)
Ambient Air Temperature Operating Range
Celsius -8°C to 43°C
Fahrenheit 0°F to 0°F
Maximum Wind Speed
Gust or steady 45 km/h (28 mph)
Vibration less than 2.5 m/sec 2
Sound Threshold below 97 dB(A)
