2. SAFETY DEVICES
2 - 5 P/N 0191915
EMS TABLE
LIGHT CONDITION AUDIO ALARM
EMS
STATUS
ON: Machine is ready for normal operation.
FLASHING: Calibration error. Notify qualified service
technician. DO NOT USE MACHINE.
None.
None.
EMS
ENVELOPE
OFF: Platform is well inside the safe working envelope.
FLASHING: Platform is less than 3 feet (1 m) inside the
safe working envelope.
ON: Platform is outside the limits of the safe working
envelope.
None.
None.
None.
EMS
WARNING
ON: EMS error detected. Press the red EMS WARNING
light completely in and release it
slowly. If the red EMS
WARNING light stays on, use the emergency
procedures described in the “EMERGENCY
OPERATION” chapter to retrieve the platform.
FLASHING: Platform is outside the limits of the safe
working envelope. Move boom into safe working
envelope.
Continuous tone.
Beeping
T
OPERATOR HORN
The operator HORN button is on the right side
of the platform-control box. It is used primarily
to get the attention of people on the ground
when you are working aloft.
The horn itself is located below the tilt alarm
sensor, it is the same horn used to sound the
tilt alarm. For the horn to work the BATTERY
switch must be ON and the following switches,
on the ground-control box, must be set as
indicated:
SELECTOR SWITCH..........PLATFORM
EMERGENCY STOP... ...........pulled out
MASTER KEY SWITCH....................ON
GREEN
WHITE
RED
