■ General Specifications—SP20
Working height . . . . . . . . . . . . . . . . . . . 20.3m (66’)
Maximum platform height . . . . . . . . . . . 18.3m (60’)
Horizontal outreach . . . . . . . . . . . . . . . 15.8m (50’)
Turntable rotation . . . . . . . . . . . . . 360° continuous
Main boom
Articulation . . . . . . . . . . . . . . . . . . . . -16° to +72°
Platform
Dimensions
Standard . . . . . . . . . 760 x 1830mm (30” x 72”)
Optional . . . . . . . . . 30² x 96² (76 cm x 244 cm)
Guardrail height . . . . . . . . . . . . . 1100mm (43.3”)
Rated work load. . . . . . . . . . . . . . 227 kg (500 lb)
Rotation. . . . . . . . . . . . . . . . . . . . . . . . . . . . 180°
Maximum number of occupants . . . . . . . 2 people
Cycle times
Turntable rotation . . . . . . . . . . . . . . . 115/120 sec
Main boom
Up . . . . . . . . . . . . . . . . . . . . . . . . . . 45/50 sec
Down . . . . . . . . . . . . . . . . . . . . . . . . 45/50 sec
Extend . . . . . . . . . . . . . . . . . . . . . . . 65/70 sec
Retract. . . . . . . . . . . . . . . . . . . . . . . 55/65 sec
Platform rotation . . . . . . . . . . . . . . . . . . 16/20 sec
Drive system
Standard . . . . . . . . . . . . . . . . . . . . 4-wheel drive
Steering system
Standard . . . . . . . . . . . . . . . . . . . . 2-wheel steer
Tires, 14ply
Foam filled . . . . . . . . . . . . . . . . . . 15 x 19.5 HD
Gradeability . . . . . . . . . . . . . . . . . . . . . . . . . . 40%
Drive speed
High . . . . . . . . . . . . . . . . . . . . . 3.2 km/h (2 mph)
Low . . . . . . . . . . . . . . . . . . . 0.87 km/h (0.5 mph)
Turning radius, inside
Inside . . . . . . . . . . . . . . . . . . . . . . . 3.8m (12’ 2”)
Outside. . . . . . . . . . . . . . . . . . . . . . . . 6.1m (20’)
Tailswing
Stowed. . . . . . . . . . . . . . . . . . . . . . 225mm (8.8”)
Overside . . . . . . . . . . . . . . . . . . . 850mm (33.5”)
Stowed height . . . . . . . . . . . . . . . . 2790mm (9’ 2”)
Stowed width . . . . . . . . . . . . . . . . . 2380mm (7’ 9”)
Stowed length . . . . . . . . . . . . . . . 8790mm (28’ 9”)
Wheelbase. . . . . . . . . . . . . . . . . . . 2600mm (8’ 6”)
Ground clearance . . . . . . . . . . . . . . 370mm (14.5”)
Axle oscillation . . . . . . . . . . . . . . . . . . . . . . . . . 7.8 0
Maximum single wheel load . . . . 5780kg (12716 lb)
Weight . . . . . . . . . . . . . . . . . . . 10250kg (22550 lb)
Ground bearing strength
Minimum. . . . . . . . . . . . . . . . . . . 441kPa (64 psi)
Electrical system
Voltage. . . . . 12 V DC negative chassis ground
Source . . . . . 1 - 12 V 15 plate 600 CCA battery
Fluid recommended . . . . . . . . . . . distilled water
Hydraulic system
Maximum pressure . . . . . . . . . 3250 psi (224 bar)
Reservoir capacity . . . . . . 100 litres (26.3 US gal)
System capacity . . . . . . . 129 litres (33.9 US gal)
Maximum operating temperature . . . 93°C(200°F)
Hydraulic fluid recommended
Shell Tellus T37 . . . . . . . . . . . . . . . . . . . . . . . .
Engine . . . . . . . . . . . . . . . . . . . . . . . . . . Deutz F4L
Optional . . . . . . . . . . . . . . . . . . . . . Cummins 4B
Fuel tank capacity. . . . . . . . 100 litres (26.3 US gal)
Ambient air temperature operating range
Celsius . . . . . . . . . . . . . . . . . . . . . -18°C to 43°C
Fahrenheit. . . . . . . . . . . . . . . . . . . . 0°F to 110°F
Maximum wind speed
12.5m/sec . . . . . . . . . . . . . . . . 45 km/h (28 mph)
page 1 - 4 SP20/SP22 – 11890A
Chapter 1. Specifications
