Snorkel SP18 - Manual (Page 44)

No Part No Description Req
1 0070541 Decal - Blue arrow 3
2 0070540 Decal - Yellow arrow 3
3 12044 Decal - Lug nut torque 4
4 0323896 Decal - Danger electrocution 5
5 0073298 Decal - Foam filled tires 2
6 0112471 Decal - Snorkel 2
7 0073667 Decal - Inspect wire ropes 4
8 0190989E Decal - Do not reach 1
9 451986 Decal - Limit switch 2
10 0323897 Decal - Must not operate 2
11 9212 Decal - Diesel 2
12 451776 Decal - Hydraulic fluid level 1
13 302950 Decal - Hydraulic oil min/max 1
14 9207 Decal - Hydraulic oil 1
15 0073492 Decal - Greasing instruction 1
16 11854 Decal - Lower control valve SP17 1
11875 Decal - Lower control valve SP18 1
17 11857 Decal - Lower control box 1
18 9751 Decal - New Zealand made 1
19 11868 Decal - Engine tray latch 1
20 0102006 Decal - Battery disconnect 1
21 0070901E Decal - Serial number 1
23 0072531 Decal - Electrocution hazard 1
24 11855 Decal - Upper controls SP17 1
11874 Decal - Upper controls SP18 1
25 11856 Decal - Upper controls switch panel
SP17
1
11873 Decal - Upper controls switch panel
SP18
1
26 562426 Decal - Literature compartment 1
27 0150448 Decal - Harness points 1
28 2025-227 Decal - Platform capacity 1
29 1843 Decal - Warning, New Zealand only 1
9428 Decal - Electrical hazard, Australia
only
1
30 99228 Decal - Safety harness 1
31 0073668 Decal - Do not use boom 1
32 300699 Decal - Operation check list 1
33 0323899 Decal - Electrocution hazard 1
No Part No Description Req
34 11971-1 Decal - SP17 2
11971-3 Decal - SP18 2
35 11971-2 Decal - SP17 1
11971-4 Decal - SP18 1
Figure 6.23—Standard Feature
Placards and Decals
page 7 - 10 SP17/SP18 – 11972A
Chapter 7. Pre-operational Inspection
■ Placards and Decals
Figure 6.23 provides the item number, Snorkel part number, description, and the quantity of each placard
and decal required for standard aerial platform features.
Inspect all safety and operational placards and decals. Make certain they are in place, in good condition,
and are legible.
Replace any missing or illegible placards or decals before operating the aerial platform. Placard and decal
kits are available from Snorkel dealers.
