Danger – Snorkel S2033CE User Manual
Page 33
Chapter 8 – Prestart Inspection
S2033 – 330003EE
29
Rear
Hydraulic Tray
0074311
0074311
300740
300740
0074311
300740
Inside Stack
475596
(One on each brake cylinder)
THIS CYLINDER IS SPRING LOADED. INCORRECT
ASSEMBLY OR DISASSEMBLY COULD CAUSE
PHYSICAL INJURY. BEFORE REMOVING SNAP
RING, RETRACT CYLINDER ROD .25 INCH.
REMOVE SNAP RING AND SLOWLY EXTEND
CYLINDER ROD UNTIL SPRING PRESSURE IS
RELEASED. ASSEMBLE IN REVERSE ORDER.
475596
302820
302820
302820
DANGER
DO NOT ALTER OR DISABLE
LIMIT SWITCHES, SAFETY
SWITCHES, OR INTERLOCKS.
451986
451986
451986
