OPERATOR’S MANUAL

with Maintenance Information

Schematic

30

No.

Symbol

Description

Specification

Q’ty

1

IN/OUT

Controller Box

1

2

YV

Lower Valve Coil

DC 24V

1

3

KTF

Time Relay

H3Y-2DC24V5A

1

4

KAF

Intermediate Relay

MY2NJDC24V5A

1

5

RH

Power Light

XB2-BVM4LC

1

6

SB2

Emergency Stop Switch

ZB2BS5C/102C

1

7

SB1

Key Switch

ZB2BG2C/101C

1

8

KM2

Pump Contactor

W800801 80%

1

9

KM1

Power Contactor

MZJ-200S1 100A

1

10

FU2

Fuse

10A

1

11

FU1

Fuse

100A

1

12

SBS

Power Emergency Stop Switch

200A

1

13

SQ1

Low Limited Switch

TZ8108 5A

1

14

E

Battery

DC12V/95Ah

2

15

M3

Hydraulic Pump Motor

DC12V800W

1

16

M2

Right Drive Motor

DC24V400W

1

17

M1

Left Drive Motor

DC24V400W

1

18

JSM

Joystick

V 0~5V

1

19

Rnee

Controller Rnee

DC24V100A

1

20

QQE

Battery Charger

DC24V15A

1
