OPERATOR’S MANUAL
with Maintenance Information
Operating Instructions
22
Battery and Charger Instructions
Observe and Obey:
√ Do not use an external charger or booster
battery.
√ Charge the battery in a well-ventilated area.
√ Use proper AC input voltage for charging as
indicated on the machine.
√ Use only a UPRIGHT authorized battery and
charger.
Dry Battery Filling and Charging
Instructions
1 Remove the battery vent caps and
permanently remove the plastic seal from
the battery vent openings.
2 Fill each cell with battery acid (electrolyte)
until the level is sufficient to cover the
plates.
Do not fill to the maximum level until the battery
charge cycle is complete. Overfilling can cause
the battery acid to overflow during charging.
Neutralize battery acid spills with baking soda
and water.
3 Install the battery vent caps.
4 Charge the battery.
5 Check the battery acid level when the
charging cycle is complete. Replenish with
distilled water to the bottom of the fill tube.
Do not overfill.
To Charge Batteries
1 Be sure the batteries are connected before
charging.
2 Open the battery compartment. The
compartment should remain open for the
entire charging cycle.
Maintenance - free batteries
3 Connect the battery charger to a grounded
AC circuit.
4 The charger will indicate when the battery
is fully charged.
Standard Batteries
3 Remove the battery vent caps and check
the battery acid level. If necessary, add
only enough distilled water to cover the
plates. Do not overfill prior to the charge
cycle.
4 Replace the battery vent caps.
5 Connect the battery charger to a grounded
AC circuit.
Note: For optional charger/inverter, connect AC
power to the plug on the back of the machine.
6 The charger will indicate when the battery
is fully charged.
