Control panel, Platform joystick controller, Ground control panel – Snorkel SPX10 User Manual
Page 12
OPERATOR’S MANUAL
with Maintenance Information
Control Panel
8
`
Joystick Control Panel
Platform Joystick controller
1 On-off button
5 Accelerating button
2 Horn button
6 Battery indicator light
3 Mode button
7 Mode indicator
4 Decelerating button
8 Drive speed indicator
3
2
1
Ground Control Panel
1 Key switch
2 Power indicator
3 Red Emergency Stop button
