December 2008 Instruction Manual
Page1
Chapter 1 Preface
Read this manual carefully before the machine is taken into use to avoid errors. Correct
operations and regular inspections are factors of vital importance for the operating
economy and lifetime of the machine.
These important parts are described in the following related sections.
Alloy aluminum mast mobile elevating work platform is the most ideal equipment for
aerial work. Single mast mobile elevating work platform is intended to move one person
along with the necessary tools and materials to working position where he will carry out
work on the work platform.
They are generally intended for use on plane and level floors. They are mainly used for
business decoration, industrial facilities maintenance, lamps and lanterns replacement
in halls, maintenance of street lamps, aerial photography and wall cleaning etc.
The single mast mobile elevating work platform has the following characteristics:
1.1 Lift or fall steadily: The seamless transmission is used between the lifting masts,
thus minimizing the amount of sway after lifting.
1.2 Safe and reliable: The four turning stabilizers of the unit connected to the four
corners of the chassis support the MEWP during work. They are designed for leveling
regulation and preventing inclination. They are composed of stand bars and turning
legs. The stand bars are installed in the turning legs. Extending out the turning legs
before operating the unit enlarges the area of supporting. Therefore, the steadiness of
the whole platform is guaranteed.
1.3 Convenient: The whole work platform is light because the lifting masts are made of
alloy aluminum. The structure is compact and the volume is small, so only one person
can move the equipment and carry it through a very narrow passage.
All the information contained in this booklet is based on the data available at the time of
printing; the manufacturer reserves the right to modify its products at any time, without
notice and without liability. It is therefore advisable to regularly check for any changes.
Chapter 2 Specifications
Technical specifications and major dimensions are shown in Table 1 and Figure 1,
respectively.
Table 1
Power
rating
Stored
dimension
L×W×
Machine
weight
Model
Max.
platfor
m
height
Max.
workin
g
height
Rate
d
load
The
number of
persons
allowed on
platform
Platfor
m
size
A×B
Outrigge
r
footprint
C×D
AC
DC
DC
AC
DC
mm mm k
g Person(s) mm mm kw mm kg
PAM21 6500 8500 125 1 600Ч600 1740Ч1786 0.75 1.5 1252Ч715Ч1967 310 345
PAM26 8000 10000 125 1 600Ч600 1740Ч1786 0.75 1.5 1252Ч715Ч1967 365 395
