Snorkel PAM26-sn000001+ - Manual (Page 19)

December 2008 Instruction Manual
Page13
PAM SERIES DECAL INSPECTION(SINGLE)
serial
numbe
r
Part No. Descripti
on
QTY.
16 062840-900 Control panel on work platform 1
13 13479-26 AC Control panel 1
13 13479-27 DC control panel 1
16 510425-201 Machinery label 1
7 13479-5 Leveling and justment(lift) 2
6 13479-6 Leveling and justment(right) 2
4 13479-21 Brief operating instruction 1
5 13479-22 Gate of platform 1
17 13479-28 Label—Back-up 1
11 13479-7 Warning—Make sure to position the stabilizers before operating 4
11 13479-8 Max. Load on each stabilizer—2800N 4
2 13479-11 Capacity:125kg 1
10 13479-3 Warning—Make sure the chock is in place during maintenance 1
10 13479-4 Warning—shearing danger, keep hands away 1
4 13479-20 Notice—Allowed number of persons: ONE 1
4 13479-9 Max. Allowed Manual force—200N 1
4 13479-10 Max. Allowed wind speed—12.5m/s 1
1 13479-12 Warning—Keeping safe clearance with live electric conductors 1
1
13479-13
Caution— The masts or the platform must not bump into any
barrier or moving object during lifting
1
1 13479-14 Warning—Ensure all atabilizers are engaged properly before
elevating the platform
1
2
13479-15
Warning—The manual forces applied by persons on the work
platform should not
1
2 13479-16 Danger—Any unsafe operation pattern on the platform is strictly
forbidden
1
3 13479-17 Danger—Don′t move the whole equipment when in the course of
lifting and lifted
1
3
13479-18 Danger— The addition of any device, such as ladder, to increase
the working height is strictly not allowed.
1
3
13479-19
Danger-- Don′t park at the slope, pay attention to the obstacle
when moving at the slope.
1
4 13479-2 CE label 1
8 13479-1 Danger—Please don′t stand 1
12 13479-24 Caution—Electrocution hazard 1
12 13479-25 Notice—The charging socket of the battery (For DC) 1
12 13479-23 Notice—Recharging lasts at least 12 hours (For DC) 1
9 511099-000
Label—Snorkel
15 511103-000
Label—PAM26
Decal Inspection:
Use the pictures on the next page to verify that all decals
are legible and in place.
Below is a numerical list with quantities and descriptions.
