● Nameplate and CE mark
Snorkel,
Vigo Centre, Birtley Road,
Washington, Tyne & Wear,
NE38 9DA, U.K.
MODEL
NUMBER PAM26 SERIAL
NUMBER
MONTH / YEAR
OF MANUFACTURE
ASSEMBLED IN CN
NON-LOADED
MACHINE
WEIGHT
---
340
lbs
kg
ENGINE
POWERED
MODELS
hp
N/A
kW
DRIVE
BATTERY
POWERED
MODELS
N/A V
MAXIMUM
OUTRIGGER
LOAD
---
285.4
lbs
kg MOTORS
12 V
MAXIMUM
BATTERIES 100 Ah
% CHARGER
GRADEABILITY
N/A
INPUT
115 - 230 V
MAXIMUM
ALLOWABLE
Indoors Outdoors
MANUAL FORCE
(SIDE PULL)
---
200
---
200
lbs
N
MAXIMUM
PLATFORM
HEIGHT
RATED NUMBER
---
8
Indoors
ft
m
Outdoors
MAXIMUM
ALLOWABLE
WIND SPEED
MAXIMUM
PLATFORM
---
10.7
mph
m/s
ft
OF OCCUPANTS
1 1
REACH
N/A
m
MAXIMUM
PLATFORM
LOAD
125Kg = 1 Persons
+ 45Kg Tools
MAXIMUM
DRIVE
HEIGHT
ft
N/A
m
SLOPE SENSOR ALARM SETTING MAXIMUM lbs
FRONT TO
BACK
SIDE
TO SIDE
0 deg WHEEL
LOAD N/A
kg
CAUTION
ONLY trained and authorised personnel may operate this machine.Consult the Operation Manual before using this machine.
DO NOT make any changes to this machine, any changes made will invalidate the manufactures warranty and
may contravene legislation.
Axle weights with machine in the stowed position.
STEER AXLE
DRIVE AXLE
---
---
lbs
lbs ---
---
kg
kg
510425-201
PAM26 Machine plate
