December 2008 Instruction Manual
Page28
DC ELECTRICAL COMPONENTS
No SIGN DESCRIPTION PN REMARK
1 FU1 Fuse CNN-200A
2 FU2 Fuse Fuse 6.0MM*30MM 15A
3 LED1-5 Indicator GQ/AD22-C8
4 BD Battery Disconnect CONNECTOR 175AMP
5 PB1 Key Switch XB2BG33C
6 ES1
Emergency Stop
Switch
Button XB2BS542C
7 SB1 Power Button Button XB2BA21C
8 SB2 Raise Button Button XB2BA21C
9 SB3 Lower Button Button XB2BA21C
10
SB4-
6/ES2
Upper Electric Box
11 K1-4 Intermediate Relay DRM270012LT
12 KM1 DC Contactor DC12V 200A
13 YV1 Raise Valve DC12V
14 YV2 Lower Valve DC12V
15 M1 Motor(DC) DC12V 1.5KW
