December 2008 Instruction Manual
Page5
● Operating instructions
Brief Operating Instruction
● Leveling the whole equipment
1. Pull up the aligning pin, extend outwards the turning leg, which is connected to
one of the four corners of the chassis, until the aligning pin gets into the working
aligning hole automatically.
2. Turn the handle clockwise until the supporting foundation contacts the ground for
all the four bolts, go on turning to make the road wheel away from the ground.
3. Adjust the leveling by observing the spirit level on the chassis. The bubble should
move to the center circle of the gauge when the chassis is set on an even plane.
4. To store the turning stabilizers of the unit, turn the handle counterclockwise until
the supporting foundation away from the ground. Pull up the aligning pin, retract
inwards the turning leg until the aligning pin gets into the storing aligning hole.
•
How to use the control buttons
1. Before operating the machine, all circuit breakers and the leakage breaker must be
in “ON” position on the electrical box panel.
2. The mobile elevating work platform uses two sets of upper and lower parallel
control devices.
3. On either control panels, press “UP” button for lifting and press “DOWN” button
for lowering the platform.
4. The platform rises or falls when the button is pressed. Upon loosening the buttons
the platform stops.
5. A big mushroom-shaped button is the stopping button at emergency. Press it only
if the platform can’t stop effectively in the course of rising. Reset the button by
turning the knob in the direction shown by the arrow. Do not pull the knob.
● Emergency Operation
If two sets of the upper and the lower control devices can’t make the platform fall
because of sudden power failure or other causes, turn the valve counterclockwise
and the platform will be lowered slowly. Once the platform falls down to the bottom,
the valve for emergency should be closed.
Emergency Operation
If two sets of the upper and the lower control devices can’t make the plat-
form fall because of sudden power failure or other causes, turn the valve
counterclockwise and the platform will be lowered slowly. Once the platform
falls down to the bottom, the valve for emergency should be closed.
● Warning labels
