Smittybilt 2727 Ground Anchor User Manual
Ground anchor part # 2727 (universal), Installation instructions

WWW.SMITTYBILT.COM
For Technical Support/Warranty Information please call 310-762-9944
Smittybilt, 400 West Artesia Blvd, Compton, CA 90220
Installation Instructions
Ground Anchor
Part # 2727 (Universal)
Step 1: The Ground Anchor has 3 settings depending on its need to fit for use in soil, sand and very loose
sand. (See Fig 1) The ground Anchor will work on its own, however it will achieve greater
performance with another person standing behind the anchor holding the handle to make sure the
anchor will be pulled into the soil at the correct angel.
(Fig 1)
Note: A tire or other round object is recommend to use to eliminate damage to your winch cable
from it contacting the ground surface.
NOTE: Carefully read entire instructions and product information thoroughly before
attempting to install/use this part. Use caution when using this product.
Rated Load capacity 10,000 LB, Max Load Capacity 12,000LB
Hand
Operated
Hoist
