WWW.SMITTYBILT.COM
For Technical Support/Warranty Information please call 310-762-9944
Smittybilt, 400 West Artesia Blvd, Compton, CA 90220
Installation Instructions
Defender Rack Mounts
Universal
Part # HD-2, HD-4, HD-6, HD-8,HDS-2, HDS-4,
HDS-6, HDS-8, HD-10, HDS-10, HD-12, HD-12S
PART # HD-10 or HDS - 10
Parts Included Qty Parts Included Qty
Clamp (#HD) 10 5/16” Flat Washer 80
“L” Bracket (#D8099B) HD 10 5/16” Lock Washer 40
“L” Bracket (#D8108A) HDS 10 5/16” Nut 40
Hardware Kit (#HD-10-HP) 5/16” x ¾” Bolt 40
PART # HD-12 or HDS - 12
Parts Included Qty Parts Included Qty
Clamp (#HD) 12 5/16” Flat Washer 96
“L” Bracket (#D8099B) HD 12 5/16” Lock Washer 48
“L” Bracket (#D8108A) HDS 12 5/16” Nut 48
Hardware Kit (#HD-12-HP) 5/16” x ¾” Bolt 48
Step 1: Assemble the bracket assemblies, and place on each side of factory rails per diagram.
Do not tighten at this time.
Step 2:
Position roof rack on brackets and attach with 5/16” hardware.
Step 3:
Once the rack and brackets are in the desired location, tighten all hardware.
