Smittybilt 90112B EXPEDITION RACK User Manual
Installation instructions

WWW.SMITTYBILT.COM
For Technical Support/Warranty Information please call 310-762-9944
Smittybilt, 400 West Artesia Blvd, Compton, CA 90220
Installation Instructions
EXPEDITION RACK
97-06 TJ,04-06 LJ
Part # 90112B, 90113B
Parts Included Qty
Parts Included Qty
Driver Front Support (90111B-1) 1
½” Lock Washer 6
Pass. Front Support (90111B-2) 1 7/16” x 1” Bolt 6
Driver Rear Support (90111B-3) 1 7/16” Flat Washer 12
Pass. Rear Support (90111B-4) 1 7/16” Lock Washer 6
Driver Windshield Brkt (90112B-5) 1
7/16” Nut 6
Pass. Windshield Brkt (90112B-6) 1 5/16” x 1 ‘ Bolt 6
Driver Taillight Bracket (90112B-7) 1 5/16” Flat Washer 6
Pass Taillight Bracket (90112B-8) 1
5/16” Lock Washer 6
Short Support Bar (90112B-9) 5 ¼” x 1 ¼” Bolt 4
Long Support Bar (90113B-9) LJ 5
¼” x 1’ Bolt 16
Hardware Pack (90112-HP1)
¼” Flat Washer 40
½” x 3 ½” Bolt 2
¼” Lock Washer 20
½” x 1” Bolt 4
¼” nut 20
½” Nut 2 Urethane Bushing 4
½” Flat Washer 8
½” ID Steel Sleeve 2
Note:
Defender Roof Racks are rated for loads of no more than 150lbs. evenly distributed.
When carrying a spare tire, the tire should not exceed 33” diameter
Please read instructions entirely before installing this product. Drilling is
required to install this part.
