Installation Instructions

XRC Front Bumper

(Part #76800 1997-2006 Wranglers)

(Part#76801 1987-1995 Wranglers)


Parts Included Qty

Parts Included Qty

Front Bumper 1

8 mm Hex Bolt (Fairlead) 2

½ x 1 1/4 “ Bolt 6

8 mm (I.D.) Flat Washer 2

½” Flat Washer 6

8mm Locking Nut 2


Step 1:
Remove the factory front bumper from vehicle by removing the two top and the two bottom bolts.
(Figure A) Save these bolts for use later.

(Figure A)


Note:
On YJs (87-95) it may be necessary to grind down the welds slightly on top of the frame in order to
get the bumper to slide back over the frame and align mounting holes.

Step 2: Position the new bumper on the front of the vehicle. Line up the holes on the frame with the slotted
holes on the bumper brackets. Attach the bumper to the frame using the supplied bolts. (Fig B,C)

(Figure B)

NOTE: Carefully read entire instructions thoroughly before attempting

to assemble and/or install this product.

Factory
Bolt
Locations
(both sides)

The bumper attaches
to the top of the frame
using both mounting
locations.

Top Driver Side Shown

On YJs (87-95) it may
be necessary to grind
down the welds slightly
on top of the frame in
order to get the bumper
to slide back over the
frame and align

mounting holes.
