Installation Instructions
XRC Rear Bumper
(Part# 76655)
07-08 Jeep Wrangler (JK)
(Fig C) (Fig D)
Step 5: Install the four ½” x 1 ¼” bolts through the side brackets into the previously installed nut
plate.
Step 6: Make sure bumper is level and the completely tighten all hardware. Torque bolts to 90 ft-lb.
Step 7: Installation is now complete. (Fig E)
(Fig E)
Attach using the supplied ½”x 4 ½”
bolts with flat washers and lock nuts.
Install the four ½” x 1 ¼” bolts
through the side brackets into the
previously installed nut plate.
