Installation Instructions
07-09 JK Front Bumper
Part# 76722,76805,76741,76742
(Fig C) (Fig D)
Step 4: Using the four square holes on the bottom of the front bumper as a guide, center punch and drill
through the factory cross member using a ½” drill bit. (Fig E, F) Make sure there are no wires or
other obstructions in the way before drilling.
(Fig E) (Fig F)
Carriage
Bolt
12 mm Hex Bolt,
flat washer, lock
washer
Flat washer,
lock washer,
nut.
