Installation Instructions
Extended Top (Part #,936xx)
1997-2006 Jeep Wranglers
For Technical Support/Warranty Information please call 310-762-9944
Smittybilt, 1600 Walnut Parkway, Compton, CA 90220
Option 2 (without J-Clip)
Figure 13
10. Wrap the straps around the seat belt shoulder
harness and roll bar. Feed the loose end through the
buckle on the other end and pull tight (Figure 13).
Be sure not to interfere with the seat belts safety and
operation. Place the strap under the seat belt.
Never install over the seat belt strap.
Figure 14
11. Locate two straps in the middle of each side of the
Brief. For each side, wrap the straps around the
vertical roll bar, then feed the loose end through the
buckle on the other end and pull tight (Figure 14).
Tighten all straps (including the center strap). Tie off
loose strap ends.
12. Re-adjust Velcro and tighten all straps to assure a
wrinkle-free fit.
13. Installation is now complete
