Installation Instructions
Tonneau Cover (#7010XX-7210XX)
1987-95 Jeep Wranglers
For Technical Support/Warranty Information please call 310-762-9944
Smittybilt, 400 West Artesia Blvd, Compton CA 90220
2. Lay the Tonneau over vehicle and wrap around the roll bar at the rear of the vehicle (Figure 3).
3. Lift flap on rear of Tonneau and slide factory tailgate channel on Tonneau retainer. Insert channel
back onto vehicle (Figures 4 and 5).
Figure 3
Figure 4 Figure 5
