Installation Instructions
Jeep Rear Hitch (Part # JH44)
1987-2006 Jeep Wranglers
Step 3: Temporarily attach the hitch to the vehicle frame by installing (1) 10mm bolt (2) 10 mm flat washers
(1) 10mm lock washer and (1) 10 mm nut in each of the two outer holes on both sides. Now mark
each of inner 2 holes on both sides on the frame. Now remove the hitch from the frame.
(Figure 3-6)
Mount the Hitch Mark the Inner Holes
Fig 3 Fig 4
Fig 5 Fig 6
(Figure 3-6) Remove Rear Hitch
