Installation Instructions
G.E.A.R. Tailgate Cover
TJ (Part # 56622xx)
07-11 JK (Part # 56623xx)
Parts Included Qty
Parts Included Qty
G.E.A.R. Tailgate Cover 1
Self-tapping Screw 10
Step 1: Position tailgate cover on tailgate in the optimal location. Pull tight and either tape on,
or with assistance have someone hold it, then use a scribe to mark holes. (Fig A, B)
Note: On 2011 vehicles you will first need to remove the tailgate support bracket from
the tailgate using a #30 torx bit. (Fig E)
Step 2: Once all holes are marked set cover to the side and drill the marked holes using a 7/64”
dill bit. (Before drilling make sure there are no obstructions) Fig C
Step 3: Now install the included screws. (Make sure not to over-tighten) (Fig D)
(Fig A) (Fig B
(Fig C) (Fig D)
NOTE: Please read instructions entirely before installing this part.
Use a scribe to
mark holes.
Position tailgate cover on
tailgate in the optimal location
Drill the
marked
holes using
a 7/64” bit
Install the
included screws
