Installation Instructions
Security Floor Console(Part #317xx)
1976-1995 Jeep CJ &Wranglers
2)
Position the Security Floor Console between the seats and mark the floor directly under the mounting
holes in the bottom of the console (Figure 3). NOTE: Position the Security Floor Console directly behind
the shift boot, check to make sure that the shift lever will not interfere with the cup holder.
3)
Remove the Security Floor Console, cut holes in the carpet where the marks are and drill a 3/8” hole in
each marked spot (Figure 4). WARNING! Make sure that there is nothing under the vehicle that
will be damaged by the drill bit when drilling.
Figure 3 Figure 4
