Installation Instructions
Light Bar Part # 76911
07-11 Wrangler &Unlimited
Light Bar Part # 76910
97-06 Wrangler and Unlimited
Parts Included Qty
Parts Included Qty
Driver Side Upright 1
3/8” x 1 ½” Bolt 2
Passenger Side Upright 1
3/8” Flat Washer 2
Center Bar 1
Closed End Cap 2
Open End Cap 2
Step 1: Remove five of the factory bolts on the driver side windshield frame bracket. (Fig A)
Step 2: Remove the same bolts on the passenger side.
Step 3: Install each side upright bracket using the previously removed five factory bolts. Do not fully secure
at this time. Use caution when doing this in order to protect the finish of your vehicle.
Step 4: Push on the open ended style end caps on the ends of the top of the uprights. (Fig B)
Step 5: With assistance install the center light bar section using the included hardware. (Bolt and Flat
Washer) Note: The light mounting tabs point towards the rear of the vehicle with the flat
surface facing up.
(Fig A)
(Fig B)
(Fig C)
Step 6: Tighten the two end bolts completely making sure the center light bar is at your desired position.
Note: Read instructions entirely before installing this product.
