Fig 2

Fig 3

Front Passenger Side Mounting Bracket

Center Passenger Side Mounting Bracket

Rear Passenger Side

Mounting Bracket

Fig 4

Fig 5

Mounting holes
towards the
front of vehicle

Factory bolts

Factory Bolts

8mm Bolts,

8mm Lock

Washers, &

8mm Washers
