Installation Instructions
SURE STEP (Part # TN1170-S4)
05-06 Toyota Tacoma Ext. Cab
STEP 3. Loosely attach the front bracket to the body panel using the 8mm hex bolts, and 5/16” washers.
STEP 4. Locate the threaded holes in the body panel,at the rear of the cab.
STEP 5. Loosely attach the marked rear brackets, to the body panel using the 8mm” hex bolts, and 5/16” washers.
DRIVER SIDE FRONT BRACKET
8MM HEX BOLTS & 5/16” WASHERS
DRIVER SIDE REAR BRACKET MOUNTING POINTS
