For Technical Support/Warranty Information please call 310-762-9944
Smittybilt, 1600 Walnut Parkway, Rancho Dominguez, CA 90220
Installation Instructions
Sure-Step (Part # TN1140-S4)
04-06 Toyota Tundra Crew Cab
Fig #2
Fig #3
Fig #4
Be sure to use all hardware supplied and tighten all bolts.
IMPORTANT: side bars have a 300 lb. weight capacity. To protect your investment, wax this product after
installing. Regular waxing is recommended to add a protective layer over the finish.
M12
Rear support
bracket
Rear support
bracket
Place spacer inside
frame
Front support
bracket
Front backup bracket
