Installation Instructions
Sure Steps (Part # MN1440-4S)
2004-2005 Nissan Titan
Extended Cab 4 Door
WWW.SMITTYBILT.COM
QTY DESCRIPTION
1 Sure-Step, left side
1 Sure-Step, right side
1 hardware kit
NOTE: Please read this information before installing. Check components received with components listed
above.
NO DRILLING REQUIRED for installation of these Sure-Step side bars. To obtain correct installation, we
recommend you to follow these step by step installation instructions carefully. Please take care when
installing this product to protect the finish and your investment.
Step One: Locate the hardware kit and check contents with the hardware list below.
QTY
DESCRIPTION
6 8mm x 25mm hex head bolt, zinc plated GR5
12 8mm flat washer, zinc plated
6 8mm lock nut, zinc plated
12 10mm-1.25 x 30mm hex head bolt, zinc plated GR8.8
12 10mm flat washer, zinc plated
12 10mm split lock washer, zinc plated
3 support bracket, left side-black
3 support bracket, right side-black
Step Two: Locate the driver side bar, three left side brackets, six 10mm hex bolts, six 10mm flat washers, and
six 10mm lock nuts. Using the hardware listed in this step, secure the brackets to the side bar as
shown in the photo below. Do not fully tighten hardware at this time.
Step Three: Locate three 8mm hex head bolts, six 8mm flat washers, and three 8mm split lock nuts. Using
the hardware listed in this step secure the brackets to the side of the frame as shown in photo
below. Fully tighten hardware at this time.
