Smittybilt 51040 Bull Bar - Manual (Page 2)

For Technical Support/Warranty Information please call 310-762-9944
Smittybilt, 400 West Artesia Blvd, Compton, CA 90220
Page 2 of 3
Installation Instructions
Bull Bar (#51039&51040)
07 CHEVY SILVERADO 2500 HD / 07 GMC SIERRA
2500 HD
Installation Complete
Figure 1 Figure 2
Figure 3 Figure 4
Figure 5
(Passenger Side Bracket Installation Shown)
12mm x 35mm Hex Head
Bolts,
12mm Lock Washers,
12mm Hex Nuts, &
12mm Flat Washers 8mm x 25mm Hex Head Bolt,
8mm Lock Washer, &
8mm Flat Washer
10mm x 30mm Hex Head
Bolts,
10mm Lock Washers,
10mm Hex Nuts, &
10mm Flat Washers
Some cutting might be
necessary around here
