12
5.2 Installation of the power unit
1 7 5
4
3
9
10
2
11
12
13
14 15
1 Petrol tank
2 Hydraulic
À uid tank
3 Engine with hydraulic pump
4 Connecting block with
control valves
5 Speed adjusting lever
6 Carrying handle
7 Cable-pull starter
8 Valve control lever
9 "TURBO" control lever
10 Mono-coupling (female)
11 Fuel tank cap
12 Filler cap hydraulic
À uid
13 Frame
14 Rubber buffer
15 Side panel
16 Air
¿ lter
17 Choke
18 Fuel tap
19 ON/OFF switch (engine
switch)
22 Engine oil
¿ ller cap/dipstick
23 Fill level indicator
Equipment back
16
17 18 19
23
22
