30 Appendix AXD Tools Test Reference
AXD EFI Tools Tests
These tests are available if your Xserve is running AXD EFI tools.
Boot ROM Tests
Ethernet Controller Tests
Fan Tests
Memory (ECC) % Tests for memory ECC errors. This test
clears the error count, so it should be
run first (before running any other
memory tests).
Power supply % %
Sensor % % AXD Mac OS X tools has an additional
sensor test.
USB port % %
Video controller % % AXD Mac OS X tools have more tests
than AXD EFI tools.
Component tested
Available in AXD
EFI tools Available in AXD
Mac OS X tools
Notes
Test Estimated completion time Description
Boot ROM Checksum 1 second Verifies the Boot ROM checksum
Boot ROM FW GUID MAC
Addr Checksum 1 second Verifies the Boot ROM FireWire GUID
MAC address checksum
Test Estimated completion time Description
MAC Address Verification 1 second Verifies MAC address isn’t all FFs or
00s
PCI-E 4 LinkWidth Verification 1 second Verifies PCI link width is 4
Test Estimated completion time Description
Quick Motor 1 second Verifies that the fan motor can be
turned on. Reads the set point of the
motor and verifies that the motor is
spinning within 20% of the set speed.
