Class1 ENFO IV User Manual
Page 8
Enfo IV (109050) 090303
– 8 –
Class 1
Wiring Installation
Amp connector: 776286-1
Class1 PN: 106297
Amp pins:
770520-1
Class1 PN: 106298
1
CAN High
Data SAE J1939 (HI)
INPUT/OUTPUT
2
CAN Low
Data SAE J1939 (LO)
INPUT/OUTPUT
3
CAN Shield
Shield
4
System Power
+10 … 32V DC
INPUT
5
System
Ground
Ground
INPUT
6
Alarm
Silence
Ground
INPUT
7 Audible
Alarm
Power
OUTPUT
8
Audible
Alarm
Ground
OUTPUT
