Class1 Electrical System Manager - Manual (Page 9)

9
Negative Master Switch and Positive Output
PN 100633 ESM / PN 100756 ESM II
TB #15 + Output Overvoltage light or Fast idle control
TB #14 - Input System Ground
TB #13 + Input Ignition (Main battery monitor voltage)
TB #12 + Input Isolated Battery monitor voltage
TB #11 - Input Load Manage Enable (shed)
TB #10 - Input Master Switch
TB # 9 + Input System Override
TB # 8 + Output Battery Low Warning Light
TB # 7 + Output Load 7 or isolated battery low light
TB # 6 + Output Load 6
TB # 5 + Output Load 5
TB # 4 + Output Load 4
TB # 3 + Output Load 3
TB # 2 + Output Load 2
TB # 1 + Output Load 1
Positive Master Switch and Positive Output
PN 100767 ESM / PN 101038 ESM II
NOTE
: L
OADS
1 & 2
DO NOT SHED
,
MAIN BATTERY MONITORING ONLY
.
L
OADS SEQUENCE ON
1-7,
SEQUENCE OFF
7-1
AND SHED
7-3.
TB #15 + Output Overvoltage light or Fast idle control
TB #14 - Input System Ground
TB #13 + Input Ignition (Main battery monitor voltage)
TB #12 + Input Master Switch
TB #11 - Input Load Manage Enable (shed)
TB #10 No Connection
TB # 9 + Input System Override
TB # 8 + Output Battery Low Warning Light
TB # 7 + Output Load 7
TB # 6 + Output Load 6
TB # 5 + Output Load 5
TB # 4 + Output Load 4
TB # 3 + Output Load 3
TB # 2 + Output Load 2
TB # 1 + Output Load 1
Terminal Block I/O Polarity
