7

Electrical System Manager II

COM

N O N C

COM

N O N C

COM

N O N C

COM

N O N C

COM

N O N C

COM

N O N C

COM

N O N C

COM

N O N C

1

2

3

4

5

6

7

8

Relay LED©s

Relay Coil Input

1

2

3

4

5

6

7

8

The Electrical System Manager II is equipped
with 8 Printed Circuit Board Relays mounted in
an enclosure with the load manager. The re-
lay coil input tab should be grounded for nor-
mal installations. The common and output tabs
on each relay readily allow for custom installa-
tions.

MODE CONFIGURATION

Figure 4

Load Level 1

System Override

Load Level 5

Ignition

Load Level 3

Shed Enable

Load Level 7

Load Level 2

Master Switch

Load Level 6

Ground

Load Level 4

No Connection

Battery Warning Lt

J5

TB#1

TB#9

TB#5

TB#13

TB#3

TB#11

TB#7

TB#15

TB#2

TB#10

TB#6

TB#14

TB#4

TB#12

TB#8

A

B

Over Voltage Light
High Idle Control
