Page 3

REMOVE EXISTING WIRES FROM ECU PLUG(S)

1. Locate a small screwdriver (a precision 1.5mm wide flathead screwdriver is recommended)

and carefully pry white plastic retainer using both slots in the retainer so it disengages
vertically about 1mm as shown in figures 2 and 3 (please note: some connectors may have
a lock opposite to the wires in between the pins, these can be removed simply using a pair
of needle nose pliers):

Figure 2: Pry in these areas

Figure 3: Lock that has to move up

1mm
