Plot One
Parameter Description
Flow Measured flow rate in cc/min
Lower Flow Limit Lower flow limit value as related to Injection Percentage
Upper Flow Limit Upper flow limit value as related to Injection Percentage
Plot Two
Parameter Description
Alarm Source
Indicates what triggered the alarm condition; 1-low flow condition, 2-high flow condition, 3-auxiliary
input, 4-alarm test
Alarm Status Indicates state of alarm; 1-alarm triggered, 0-alarm not triggered
Alarm Reset Counter Counts up from zero to Alarm Reset value once flow has returned into the acceptable range
Alarm Delay
Counter
Counts up from zero to Alarm Delay value when flow occurs outside the high or low flow limits;
once full Alarm Delay value is reach the alarm will trigger; counter will reset back to zero if flow
returns back into the acceptable range once count up has began
Plot Three
Parameter Description
INJ Injection percentage value
Alarm Reset Limit Alarm Reset value
Alarm Delay Limit Alarm Delay value
Calibration Changed Indicates that a configuration setting has changed
