LeanFind Procedure—Step-by-Step
Procedure Example Comments
1 Establish cruise at approx.
65 to 75% power.
2 Pre-lean the mixture to 50°F
on the rich side of the
estimated peak EGT on any
cylinder: _____° I490
370 *For your first flight with the
EDM-760, use the method
shown below.
3 Wait one minute Let engine stabilize.
4 Tap the LF button I490
LF Start the LeanFind mode.
5 Slowly lean the mixture—
approx. 4°/second—while
observing the display. When
there is a 15°F rise in EGT,
LeanFind mode becomes
active. I520
LF
(Fuel Flow
Option
shows
flow) Flashing cylinder number
indicates hottest cylinder and
that LeanFind mode is active.
6 Stop leaning when
a column begins flashing.
You will see
PEAK EGT for
two seconds, followed by:
I550
SET
or with
Fuel Flow
I550
I 2.4
Flashing cylinder number &
column indicates leanest
cylinder. (SET means that
the peaked cylinder is “set”
into the display.) Due to
thermal inertia this will
usually be about 10°F lean of
peak.
7 If you hold LF, peak EGT will
be displayed while the LF
button is held down. I560
PEAK Captured peak EGT value is
displayed.
8 Slowly enrich the mixture. the
temperature will increase,
returning to peak.
Stop enriching at the desired
EGT.
Best economy
Best power
I560 SET
I560 SET
I460 SET
• Peak EGT for best
economy
• 100° cooler than peak for
best power
Best
power
Temperature when
column flashes
best economy
leaner richer
*Here is how to determine the pre-lean value: while in cruise at under 65
percent power, choose any cylinder and lean that cylinder to peak EGT in
the Manual indexing mode or to engine roughness, whichever occurs first.
Note the peak, subtract 50° and write the resulting number in the space
provided in step 2.
