Hyline Offroad TJ/YJ TIRE CARRIER READY REAR BUMPER User Manual
Proudly made in, Tools needed parts list, Optional winch installation
Proudly Made In
USA
Vehicle Fitment:
1987-2006 Jeep Wrangler &
Unlimited
Installation Instructions:
TJ & YJ Standard Rear Bumper
Part Number: TJ-YJ-20SRB(T)
Drill
7/16” Bit
18mm Wrench
5/8” Wrench
11/16” Wrench
Ratchet
18mm Socket
5/8” Socket
Torque Wrench
Tools Needed
Parts List
Qty:
1 Standard Rear Bumper
2 Left & Right Frame Tie-in
Brackets
2 Spacer Shims
8 7/16-20 x 1-3/4” Gr8 Bolts
8 7/16” Gr8 Flat Washers
8 7/16” Gr8 Lock Washers
4 7/16-14 x 3-1/2” Gr5 Bolts
4 7/16-14 Gr5 Hex Nut
8 7/16” Gr5 Flat Washers
4 7/16” Gr5 Lock Washers
Safety Glasses
Optional Winch Installation
Congratulations on your purchase of the Hyline Offroad Standard Rear Bumper. Our Bumpers are completely
manufactured in our facility located in Perkasie, PA. They are designed and engineered by Offroad enthusiasts just
like you to be rock solid at an affordable price. Hyline Offroad would like to thank you for your recent purchase
and look forward to serving you in the future.
Hyline Offroad Staff
