Hyline Offroad JK STANDARD FRONT BUMPER (ALL MODELS) - Manual

T:\Hyline Offroad, LLC\Installation Instructions\JK-10SFB\JK-10SFB Installation Instructions.doc Page 1 of 5
REV 3 8/3/10
Proudly Made In USA
Installation Instructions:
JK Standard & Crawler Front Bumper
Part Number:
JK-10SFB & JK-10CFB
Vehicle Fitment:
2007 - Present Jeep Wrangler &
Unlimited
Parts List
Qty:
1 Standard Front Bumper
1 Winch Plate
2 Left & Right Bumper
Mounting Brackets
8 8-32 Lock Nuts
8 8-32 Flat Washers
14 7/16-20 Grade 8 Bolts
14 7/16” Lock Washers
18 7/16” Flat Washers
4 7/16-20 Grade 8 Nuts
2 7/16-20 Weldnut Tabs
Tools Needed
Ratchet
18mm Deep Socket
6” Extention
11/16” Deep Socket
5/8” Socket
11/32” Deep Socket
Torque Wrench
5/8” Wrench
Phillips Screwdriver
Congratulations on your purchase of the Hyline Offroad Standard Front Bumper. Our Bumpers are
completely manufactured in our facility located in Perkasie, PA. They are designed and engineered by
Offroad enthusiasts just like you to be rock solid at an affordable price. Hyline Offroad would like to
thank you for your recent purchase and look forward to serving you in the future.
Hyline Offroad Staff Hyline Offroad Staff Hyline Offroad Staff Hyline Offroad Staff
