PureFlow AirDog Dodge In-Tank Modification Kit - Manual (Page 3)

3
For Fuel Module “A” In-tank style
Note: The sending unit pictured may not be the exact same as the one you have, however
installation procedure will be similar on all sending units
Step 2. Drill a 5/8 hole in the top of the Fuel Module (fig 5). Some modules can be drilled at the
unused port (fig 6), with other versions it may be necessary to remove some ribs (on top of module
only) and grind or sand flat before drilling hole to provide a good sealing surface.
Figure 5 Drill hole
In either spot
Figure 6 Figure 7
Step 3. Removing pump from module.
Cut return line & fuel line from pump and disconnect power wires. Using two or three screw drivers
carefully pry pump from its location, remove pump and the components attached to the bottom of it.
