PureFlow AirDog Dodge In-Tank Modification Kit - Manual (Page 2)

2
INSTALLING THE PUREFLOW® FUEL MODULE UPGRADE!
To access the fuel tank to install the Up Grade Kit, it is necessary to either drop the fuel tank or lift the
bed. Should you choose to pull the bed be sure to disconnect the light wires, filler tube, and any other
accessories or components that may be secured to the frame and bed.
CAUTION: If you are unsure of the proper procedure for removing the fuel tank or truck bed from
vehicle, consult your vehicle manufacturer’s service manuals for detailed instructions.
NOTE: The tank in the pictures are for example only and may not be the same as your tank.
When removing the tank, always remember Safety First!
Figure 1
Figure 2
If you choose to remove the bed, properly support the truck bed to prevent serious injury or death.
NOTE: When the original fuel supply line is disconnected, fuel will drain. After the line has drained you may want to
seal the end to prevent possible spillage later.
Step 1. Clean top of tank around the module, lock nut and threads so dirt and debris do not
contaminate tank. Disconnect electrical plug, supply and return lines. Remove fuel module.
Figure 3
Figure 4
