9 Repair parts/Optional parts
Parts Number Repair Parts Name
PDF07702H AD Power supply wire (1m, 3 1/3ft)
PDF07707H AD Meter wire （0.25m, 10in）
PDF07710H AD Meter wire (2m, 6 3/5ft)
PDF07807G AD meter cup (52mm, 2 1/16in)
PDF08606G AD meter cup (60mm, 2 3/8in)
PDF07808G AD Buffer
PDF07809G AD Installation parts for meter & ZD
PDF07812G AD Regular Position Bezel (52mm, 2 1/16in)
PDF08607 Ｇ AD Regular Position Bezel (60mm, 2 3/8in)
PDF06503S Turbo Sensor
PDF00703S Pressure Sensor
PDF00903S Temperature Sensor
PDF01103S Exhaust Temp. Sensor
PDF01105G Fitting for Exhaust Temp. Sensor
PDF06505H Turbo Sensor wire (2.5m, 8 1/5ft)
PDF08105H AD Oil Press. Sensor wire （3m, 10ft)
PDF06603H Fuel Press. Sensor wire (2.5m, 8 1/5ft)
PDF05602H Oil Temp. Sensor wire （3m, 10ft)
PDF05603H Water Temp. Sensor wire （3m, 10ft)
PDF06803H Exhaust Temp. Sensor wire (2.5m, 8 1/5ft)
PDF09705H AD Speed & Tachometer signal wire (2m, 6 3/5ft)
PDF05005G Fuse（4A） 2pcs
Parts Number Optional Parts Name
PDF07708H AD Meter wire（0.5m, 1 3/5ft）
PDF07709H AD Meter wire（1m, 3 1/3ft）
PDF06002H Turbo Sensor extension wire (1m, 3 1/3ft)
PDF06013H Pressure Sensor extension wire (1m, 3 1/3ft)
PDF00707H Pressure Sensor extension wire (2m, 6 3/5ft)
PDF06014H Temperature Sensor extension wire (1m, 3 1/3ft)
PDF00906H Temperature Sensor extension wire (2m, 6 3/5ft)
PDF01107H Exhaust Temp. Sensor extension wire (2m, 6 3/5ft)
DF09601 ADVANCE Indicator
DF09501 Fitting kit
※ For more information, contact our customer service center, or visit our website.
AD:For ADVANCE system exclusive use
Condition Possible Cause Corrective Action
○ The RPM is not
displayed correctly.
○ Wiring of the tachometer signal
is wrong.
○ Setting of the number of cylin-
ders is wrong.
○ Check wiring as per instruc-
tions in this manual.
○ Follow tachometer op-
eration manual and wiring
instruction for Speed &
Tachometer signal wire to
confirm the wiring.
○ Check the number of cylin-
ders as per instructions in
this manual.
○ This tachometer
is reading slightly
lower than the
original tachometer.
○ Generally tachometer readings
are about up to 10 % higher
than actual RPM.
○ Check if the difference is
up to 10% . This product is
designed for high accuracy
and should have little error
margin. If the difference
is much more than 10% ,
check setting of the number
of cylinders.
○ Serial line error is
displayed.
○ Communication error is oc-
curred between gauges/ZDs
and the control unit.
○ Check the meter wire as per
instructions in this manual.
If any defects are not found,
please ask the shop for
inspection.
○ Serial line errors are
displayed on all the
connected gauges.
○ More than one pressure
sensors(turbo, oil pressure, and
fuel pressure) short-circuit.
○ In case that the sensor
is broken, it need to be
changed. please ask the
shop for inspection.
