39
8 SPECIFICATIONS
Traverse
Range
x: 50mm, y: 75 mm, focus: 8mm
Resolution x and y: 10 µm, focus (z): 1 µm
Sample stage
Dimensions
X × Y: 140mm × 200mm
Opening 55 × 80 mm
Camera module
RS-170-BW
Analog, interlaced monochrome camera with 1/3
CCD 640 × 480 pixels, 30 frames/s
RS-170-C Bayer-pattern analog color camera with 1/3 CCD 640
× 480 pixels, 30 frames/s
Objectives 10× plan 0.25/170
4Ч
20Ч
Illuminator
modules LED-B: 3 blue (center 460 nm, bandwidth 50 nm), one
white bank
LED-G: 3 green (center 560 nm, bandwidth 50 nm),
one white bank
LED-R: 3 red (center 660 nm, bandwidth 50 nm), one
white
LED-W: 4 white banks
LED-RGBW: 1 red, 1 green, 1 blue, 1 white bank.
Inputs 4 programmable digital inputs, TTL level
Outputs Composite analog video out
S-video out
3 programmable digital outputs TTL level
4 external illuminator trigger/drivers, TTL level
Communication
interface Serial RS232, 9 pin D-sub connector.
