BNC 1420 - Video Microscope User Manual
Page 23
21
4.3
Upgrading firmware
The firmware is the software stored inside the Model 1420 in non-volatile
memory and controls the internal functions of the instrument, such as
traverse movements, front panel lamps and buttons, and back-panels
inputs and outputs. The firmware is included in the scopePRO application
package and can be loaded into the Model 1420 from within the
scopePRO software.
To upgrade firmware to the latest version:
1.
Download the newest version of scopePRO from
and install on your computer following
the installation procedure described in the introduction.
2.
Connect and turn on the Model 1420 and start up the
scopePROapplication on the PC.
3.
In online mode, choose 1420>Update Firmware>Update All
4.
Click OK when the update dialog box appears
5.
Wait while the firmware is updated. You can follow the progress in the
status bar at the bottom of the scopePRO main window.
6.
When the progress indicator reaches 100%, the upgrade is completed.
Important: Do not turn off or disconnect the Model 1420 or the PC while
the upgrade is in progress. This may result in loss of
communication with the instrument that requires BNC
assistance to resolve.
