24
Installation HP500 / HP800 V. 3.0
4.1.9 Remove the wooden beams
1. Remove the screws (A).
2. Remove the wooden beams (B).
4.2 Put the machine in position
4.2.1 Move the machine to the final location, with a fork-lift truck
1. Remove the machine from the pallet. Use a fork-lift truck.
2. Move the machine to the final location.
3. Connect the power cable to the net entry. Do not connect the
power cable to the wall socket.
4. Put down the machine.
4.2.2 Move the machine to the final location, with a ramp (optional)
1. Place the ramp (A).
2. Move the machine from the pallet on to the ground.
3. Move the machine to the final location.
4. Connect the power cable to the net entry. Do not connect the
power cable to the wall socket.
A
A
B
A
