Operator manual HP500 / HP800 V. 3.0
19
Move up the brush unit
1. Install the brush container.
2. Push and hold the left part of the brush maintenance
switch (A). The brush unit moves up and then back.
3. After the brush unit stops, release the brush maintenance
switch.
Close the switch plate
1. Turn the switch plate (A) upwards.
2. Move the switch plate forwards.
3. Put the brackets of the switch plate (B) on the brackets (C) of
the sensor.
A B
1
2
3
B
2x
A
C
C
