19-03-08 Page 10 of 21 3783182
BULL BAR SETUP
29. Fit both the right and left hand buffers to
the bar using M6 flange nuts. DO NOT
OVER TIGHTEN.
30. Fit 14 M6 cage nuts (10 into the wings
and four into the main pan) and four nylon
plugs to the bar.
31. Install the indicators into the bar using the
self tapping screws (8-AB X 1” pan head)
supplied with the fitting kits. Discard the
screws supplied with the indicators.
NOTE: The indicators should be installed
with the drain holes at the bottom
32. If there are no fog lights fitted to the
vehicle, fit the fog light insert supplied to
the bar. Fit the fog insert bracket to the
fog light insert with the eight pan head
screws as shown opposite.
Nylon plugs
M6 cage nuts
