RECOMMENDED SPARE PARTS
The following list will service fleets of machines (built to current production per date on the front cover) with repair
parts which can be installed in the field. Parts from the list should be replaced when inventory is depleted to keep
service parts stock supplied. For further information, contact your JLG dealer or the JLG Industries Parts Department.
91344005 534D-9/534D-10 13-1
SECTION 13
RECOMMENDED SPARE PARTS
Part Number Description Qty./Machine
BOOM ASSEMBLY
84718372 Tilt Cyl Hose, (see Figure 8-8) 1
84718373 Tilt Cyl Hose, (see Figure 8-8) 1
84718868 Boom Hose, (see Figure 8-8), (534D-9 S/N 0544001 thru 0644118, 534D-10
S/N 0366001 thru 0366088) 2
84721049 Boom Hose, (see Figure 8-8), (534D-9 S/N 0644119 & After, 534D-10 S/N 0366089 &
After) 2
91143024 Hose Sheave, (see Figure 8-8), (534D-9 S/N 0544001 thru 0644118, 534D-10
S/N 0366001 thru 0366088) 1
91343223 Hose Sheave, (see Figure 8-8), (534D-9 S/N 0644119 & After, 534D-10 S/N 0366089 &
After) 1
91033185 Bearing Pad, (see Section 2) 2
91033186 Bearing Pad, (see Section 2) 8
91123019 Bearing Pad, (see Section 2) 6
91123021 Bearing Pad, (see Section 2) 2
91143168 Bearing Pad, (see Section 2), (534D-9 S/N 0544001 thru 0644118, 534D-10
S/N 0366001 thru 0366088) 8
1001117651 Bearing Pad, (see Section 2), (534D-9 S/N 0644119 & After, 534D-10 S/N 0366089 &
After) 8
91121023 Shim, .0598, (see Section 2) AR
91121024 Shim, .0359, (see Section 2) AR
91121157 Shim, .132, (see Section 2) AR
91121082 Shim, .0598, (see Section 2) AR
91141302 Shim, .0598, (see Section 2) AR
90205870 Shim, .0598, (see Section 2), (534D-9 S/N 0544001 thru 0644118, 534D-10
S/N 0366001 thru 0366088) AR
91361048 Shim, .0598, (see Section 2), (534D-9 S/N 0644119 & After, 534D-10 S/N 0366089 &
After) AR
91121083 Shim, .0598, (see Section 2), (534D-9 S/N 0544001 thru 0644118, 534D-10
S/N 0366001 thru 0366088) AR
91361049 Shim, .0598, (see Section 2), (534D-9 S/N 0644119 & After, 534D-10 S/N 0366089 &
After) AR
91031236 Spacer, .0598, (see Section 2) 10
91121083 Spacer, .0598, (see Section 2) 4
91141303 Spacer, .0598, (see Section 2) 8
91033187 Bearing Pad, Push Beam, (see Figure 2-6) 1
91146028 Hose Take-Up Weldment, (see Figure 8-8), (534D-9 S/N 0544001 thru 0644118,
534D-10 S/N 0366001 thru 0366088) 2
91166068 Hose Take-Up Weldment, (see Figure 8-8), (534D-9 S/N 0644119 & After, 534D-10
S/N 0366089 & After) 2
91123054 Hose Take-Up Springs, (see Figure 8-8) 2
91086151 Plunger Weldment, (see Figure 2-4), (534D-9 Before S/N 0160038519, 534D-10 Before
S/N 0160038445) 1
90207902 Quick Release Pin, (see Figure 2-4), (534D-9 Before S/N 0160038519, 534D-10 Before
S/N 0160038445) 1
1001105441 Quick Switch Lock Pin, (see Figure 2-4), (534D-9 S/N 0160038519 & After, 534D-10
S/N 0160038445 & After) 1
2940074 Latch, (see Figure 3-18) 1
ENGINE
91365008 250 Hour Cummins Engine Filter Kit, (534D-9 S/N 0544001 thru 0544399, 534D-10
S/N 0366001 thru 0366342), (see Figure 4-1) 1
